Residential PV Solar Power Systems 3kw Single Phase CE CB SGS Certificate

Certification API, ISO, CB, CE

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Supply Ability 50000000pieces/Year Model NO. Hybrid Energy Storage Systems
Application Home, Industrial, Commercial Specification Mini, Standard Specification Or Customized
Certificate CE CB SGS DC Disconnect Switch 1000VDC 16A
Output Voltage (V) Customized Mounting Type Ground Mounting Roof Mounting
Mounting System Pitched Roof For Standards OEM Or ODM Accept
AC Disconnect Switch 1000VDC 20A Hybrid Inverter 3kw Single Phase
Load Power (W) 3kw, 8kw, 6kw, 5kw, 10kw Controller Type MPPT
Battery Type Lead-Acid, Lithium Ion, Hhcn-0001 Output Frequency Customized
Keywords Hybrid Energy Storage System Solar Panel Type Monocrystalline Silicon, Polycrystalline Silicon
Product Name Off Grid Solar System Transport Package Standard Packaging Or Customized
Trademark HTONETECH Origin Beijing, China
Shipping Cost To Be Negotiated| Freight Cost Calculator After-sales Service Yes
Warranty 2year Condition New
High Light

Residential PV Solar Power Systems

,

PV Solar Power Systems 3kw

,

solar system battery SGS

Leave a Message
Product Description

Product Description

HTONETECH Residential Off Grid Solar Panels Energy Storage Systsem China 300W 3038W Solar Panel Mono 450W Diesel 6000 Diesel Generator Solar Energy System 8Kw
Product Description
 Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw

System advantages:

HTONETECH off-grid power supply system, 10,000 sets of successful experience, customized services, one-stop shopping, and products meet CE certification.

1. No risk of depletion;
2. Safe and reliable, no noise, no pollution emissions, absolutely clean
3. Not limited by the geographical distribution of resources, can take advantage of the advantages of building roofs;
4. Generate and supply power on-site without consuming fuel and erecting transmission lines;
5. Energy quality is high;
6. The construction period is short, and the time spent in obtaining energy is short.

Meet the 24H operation of small equipment of 60-100W, and the operation of 3 days in cloudy and rainy days.



application:

  • Remote Areas: Solar panel battery systems are often used in remote or off-grid areas where access to the traditional power grid is limited or unavailable. They provide a reliable and sustainable source of electricity for homes, farms, or small communities.
  • Vacation Homes/Cabins: Solar panel battery systems are popular choices for vacation homes or cabins located in remote areas. They can power lighting, appliances, and other electrical needs, allowing occupants to enjoy their time off-grid without relying on external power sources.
  • Emergency Backup Power: Solar panel battery systems serve as emergency backup power during grid outages or natural disasters. They can provide essential electricity for critical appliances, medical equipment, or communication devices, ensuring safety and comfort during emergencies.
  • Mobile/Recreational Vehicles: Solar panel battery systems are commonly used in RVs, boats, and other mobile or recreational vehicles. They provide a self-sufficient power source for lighting, appliances, and charging devices while on the move.
  • Off-Grid Businesses: Remote businesses, such as eco-lodges, resorts, or off-grid farms, often rely on solar panel battery systems to meet their energy needs. These systems can power lighting, refrigeration, water pumps, and other essential equipment required for daily operations.
  •
Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw
Product Parameters


BLACK MONO SOLAR PANELS

Peak Power Watts:280W(SP280M-60)
Maximum Power Voltage:31.8V
Maximum Power Current: 8.81A
Open Circuit Voltage: 38.8V
Short Circuit Current:9.33A
Dimensions:1650x992x35mm(65.0x39.1x1.38inches)
Weight:18.6 kg (41.0 b)

SOLAX HYBRID INVERTER &DATA LOGGING STICK

Max.DC Input Power.3KW/3.7KW/4.6KW/5KW
Max.DCInput Voltage: 600V
MPPT Voltage Range: 120-550V
Rated Grid Voltage: 230V(EU)
Warranty: 5 Years (STD) 10 Years (Optional)
Wifi Stick For STD, Lan & GPRS Optional

TRIPLE-POWER LITHIUM BATTERY

Capacity(kWh): 4.5/6.3
Operating Voltage(Vdc): 85-118
Max. charge/discharge Current(A):30A
Charge/Discharge Current (A): 25A
Standard Power(kW):25
Maximum Power(kW):3
T-BAT system safety: CE, FCC, RCM, TUV (IEC 62619)

PV MOUNTING SYSTEM

Mounting Rail & Rail Splice Kit: Al6005 & SUS304Bolt.
Mid & End Clamps: 35,40,45,50mm
L Foot Asphalt Shingle Moount & Hanger BoltOptional
Cable Clip & Tie Optional
Ground Clip & Lugs Optional

Components SP3KW-HY SP3.7KW-HY SP4.6KW-HY SP5KW-HY
280W Mono Solar Panel 12 Piece 14 Piece 18 Piece 20 Piece
Dc Disconnect Switch 1 Piece 1 Piece 2 Piece 2 Piece
Hybrid Inverter X1-HYBRID-3.0T X1-HYBRID-3.7T X1-HYBRID-4.6T X1-HYBRID-5.0T
Triple Power Battery 4.5 kWh 4.5 kWh 6.3 kWh 6.3 kWh
Dc Cable 4mm2 100 meter 100 meter 200 meter 200 meter
AC Disconnect Switch 1 Piece 1 Piece 1 Piece 1 Piece
MC4 Connector 10 10 15 15
Mounting System Standards Pitched Roof ( Customized Optional)
PV Tools 1 Set


Detailed Photos
Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw
Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw
Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw




Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw
Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw
Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw
  Htonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kwHtonetech 3kw 5kw off Grid Solar System Complete Kit China 5000W 45039W Mono Perc Solar Panels Single Face 9.6kw Diesel Generator Solar Energy System 1kw

FAQ

1. Q: Are you a factory or a trading company?
A: We are a professional Solar Panels Manufacturer in China

2. How can we guarantee the quality of the product?
A: Always provide the favored buyer with a pre-production sample before mass production; Always test every product before despatching the shipments;

3. What products we can supply you?
A: Solar panels, inverter, controller, cable, support frame, and other solar power systems

4. Q: Can the product's pricing be cheaper?
A: Of course, you will be offered a very good discount with large quantities.

5.. Q: Can print our company's logo on the PV panels?
A: Yes! And we accept OEM&ODM orders.
