xModel No. | Wind And Solar Power System | Application | Home, Industrial, Commercial |
---|---|---|---|
Specification | Normal, Standard Specification Or Customized | Output Voltage (V) | 220V - 360V |
Work Time (H) | 24h | Mounting Type | Roof Mounting |
Battery Type | Lead-Acid, Lithium Ion | OEM Or ODM | Accept |
Color | White | System Type | Hybrid Solar PV System |
Solar Panel Type | Monocrystalline Silicon, Polycrystalline Silicon | Load Power (W) | 3kw, 50kw, 30kw, 8kw, 6kw, 20kw, 5kw, 10kw |
Application For | Surveillance System | Output Frequency | 50/60 Hz |
Keywords | Wind And Solar Power System | Type | Photovoltaic Solar Energy System |
Product Name | Off Grid Solar System | Transport Package | Standard Packaging Or Customized |
Trademark | HTONETECH | Origin | Beijing, China |
Supply Ability | 50000000pieces/Year | Shipping Cost | To Be Negotiated| Freight Cost Calculator |
After-sales Service | Yes | Warranty | 2year |
Condition | New | ||
High Light | Hybrid PV Solar Power Systems,PV Solar Power Systems 12X6 Cells |
Product Description
System advantages:
HTONETECH off-grid power supply system, 10,000 sets of successful experience, customized services, one-stop shopping, and products meet CE certification.
1. No risk of depletion;
2. Safe and reliable, no noise, no pollution emissions, absolutely clean;
3. Not limited by the geographical distribution of resources, can take advantage of the advantages of building roofs;
4. Generate and supply power on-site without consuming fuel and erecting transmission lines;
5. Energy quality is high;
6. The construction period is short, and the time spent in obtaining energy is short.
Meet the 24H operation of small equipment of 60-100W, and the operation of 3 days in cloudy and rainy days.
features:
- Solar Panels: Solar panels harness sunlight and convert it into electricity using photovoltaic (PV) technology. In a 3kW hybrid system, the solar component would typically consist of multiple solar panels with a combined capacity of 3kW or slightly higher.
- Wind Turbine: The wind component of the system involves a wind turbine that captures the kinetic energy from the wind and converts it into electrical energy. The size and capacity of the wind turbine would depend on the wind resources available at the installation site. In a 3kW hybrid system, the wind turbine would typically be selected to generate a portion of the overall power capacity.
- Hydro Power: The hydro component utilizes flowing water to generate electricity. This can be achieved through micro-hydro systems, which typically involve diverting a portion of a nearby stream or river to flow through a turbine, generating power. The capacity of the hydro component in a 3kW hybrid system would depend on the available water flow and head (the vertical distance the water falls).
- Charge Controller: A charge controller regulates the flow of energy between the solar panels, wind turbine, hydro system, and the energy storage system. It ensures that the batteries are charged efficiently and prevents overcharging or over-discharging, prolonging the battery life.
BLACK MONO SOLAR PANELS
Peak Power Watts:280W(SP280M-60)
Maximum Power Voltage:31.8V
Maximum Power Current: 8.81A
Open Circuit Voltage: 38.8V
Short Circuit Current:9.33A
Dimensions:1650x992x35mm(65.0x39.1x1.38inches)
Weight:18.6 kg (41.0 b)
SOLAR HYBRID INVERTER &DATA LOGGING STICK
Max.DC Input Power.3KW/3.7KW/4.6KW/5KW
Max.DC Input Voltage: 600V
MPPT Voltage Range: 120-550V
Rated Grid Voltage: 230V(EU)
Warranty: 5 Years (STD) 10 Years (Optional)
Wifi Stick For STD, Lan & GPRS Optional
TRIPLE-POWER LITHIUM BATTERY
Capacity(kWh): 4.5/6.3
Operating Voltage(Vdc): 85-118
Max. charge/discharge Current(A):30A
Charge/Discharge Current (A): 25A
Standard Power(kW):25
Maximum Power(kW):3
T-BAT system safety: CE, FCC, RCM, TUV (IEC 62619)
PV MOUNTING SYSTEM
Mounting Rail & Rail Splice Kit: Al6005 & SUS304 Bolt.
Mid & End Clamps: 35,40,45,50mm
L Foot Asphalt Shingle Mount & Hanger BoltOptional
Cable Clip & Tie Optional
Ground Clip & Lugs Optional
Components | SP3KW-HY | SP3.7KW-HY | SP4.6KW-HY | SP5KW-HY |
280W Mono Solar Panel | 12 Piece | 14 Piece | 18 Piece | 20 Piece |
Dc Disconnect Switch | 1 Piece | 1 Piece | 2 Piece | 2 Piece |
Hybrid Inverter | X1-HYBRID-3.0T | X1-HYBRID-3.7T | X1-HYBRID-4.6T | X1-HYBRID-5.0T |
Triple Power Battery | 4.5 kWh | 4.5 kWh | 6.3 kWh | 6.3 kWh |
Dc Cable 4mm2 | 100 meter | 100 meter | 200 meter | 200 meter |
AC Disconnect Switch | 1 Piece | 1 Piece | 1 Piece | 1 Piece |
MC4 Connector | 10 | 10 | 15 | 15 |
Mounting System | Standards Pitched Roof ( Customized Optional) | |||
PV Tools | 1 Set |
