1000VDC 16A PV Solar Power Systems Hybrid Solar Pv System Customized
| Certification | API, ISO, CB, CE |
|---|
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Model NO. | Hybrid Solar System | Application | Home, Industrial, Commercial |
|---|---|---|---|
| Specification | Normal, Standard Specification Or Customized | Certificate | CE CB SGS |
| DC Disconnect Switch | 1000VDC 16A | Output Voltage (V) | Customized |
| Mounting Type | Ground Mounting Roof Mounting | Mounting System | Pitched Roof For Standards |
| OEM Or ODM | Accept | AC Disconnect Switch | 1000VDC 20A |
| Hybrid Inverter | 3kw Single Phase | Load Power (W) | 3kw, 8kw, 6kw, 5kw, 10kw |
| Controller Type | MPPT | Battery Type | Lead-Acid, Lithium Ion, Hhcn-0001 |
| Output Frequency | Customized | Keywords | Hybrid Solar System |
| Solar Panel Type | Monocrystalline Silicon, Polycrystalline Silicon | Product Name | Off Grid Solar System |
| Transport Package | Standard Packaging Or Customized | Trademark | HTONETECH |
| Origin | Beijing, China | Supply Ability | 50000000pieces/Year |
| Package Size | 54.00cm * 54.00cm * 54.00cm | Package Gross Weight | 5.000kg |
| Shipping Cost | To Be Negotiated | After-sales Service | Yes |
| Warranty | 2year | Condition | New |
| High Light | 16A PV Solar Power Systems,PV Solar Power Systems Hybrid,Hybrid Solar Pv System Customized |
||
Product Description
Product Description
Wind Solar Hybrid Power System/Hybrid Solar Pv System/Hybrid Solar System Complete/Solar Power Hybrid System/Grid Hybrid Solar System/Hybrid Solar System
System advantages:
HTONETECH off-grid power supply system, 10,000 sets of successful experience, customized services, one-stop shopping, and products meet CE certification.
1. No risk of depletion;
2. Safe and reliable, no noise, no pollution emissions, absolutely clean
3. Not limited by the geographical distribution of resources, can take advantage of the advantages of building roofs;
4. Generate and supply power on-site without consuming fuel and erecting transmission lines;
5. Energy quality is high;
6. The construction period is short, and the time spent in obtaining energy is short.
Meet the 24H operation of small equipment of 60-100W, and the operation of 3 days in cloudy and rainy days.
applications:
- Remote or rural areas: Off-grid solar panel systems are often used in remote or rural areas where access to the main electrical grid is limited or non-existent. These systems can provide electricity for homes, farms, or small communities that are not connected to the centralized power grid.
- Vacation cabins or holiday homes: Solar panel off-grid systems are popular choices for vacation cabins or holiday homes located in remote areas. They provide a reliable and sustainable source of electricity for lighting, appliances, and other electrical needs when the property is not connected to the grid.
- Emergency backup power: Off-grid solar panel systems can serve as emergency backup power systems during grid outages or natural disasters. They can provide essential power for critical appliances, medical equipment, or communication devices to ensure safety and comfort during emergencies.
BLACK MONO SOLAR PANELS
Peak Power Watts:280W(SP280M-60)
Maximum Power Voltage:31.8V
Maximum Power Current: 8.81A
Open Circuit Voltage: 38.8V
Short Circuit Current:9.33A
Dimensions:1650x992x35mm(65.0x39.1x1.38inches)
Weight:18.6 kg (41.0 b)
SOLAX HYBRID INVERTER &DATA LOGGING STICK
Max.DC Input Power.3KW/3.7KW/4.6KW/5KW
Max.DCInput Voltage: 600V
MPPT Voltage Range: 120-550V
Rated Grid Voltage: 230V(EU)
Warranty: 5 Years (STD) 10 Years (Optional)
Wifi Stick For STD, Lan & GPRS Optional
TRIPLE-POWER LITHIUM BATTERY
Capacity(kWh): 4.5/6.3
Operating Voltage(Vdc): 85-118
Max. charge/discharge Current(A):30A
Charge/Discharge Current (A): 25A
Standard Power(kW):25
Maximum Power(kW):3
T-BAT system safety: CE, FCC, RCM, TUV (IEC 62619)
PV MOUNTING SYSTEM
Mounting Rail & Rail Splice Kit: Al6005 & SUS304Bolt.
Mid & End Clamps: 35,40,45,50mm
L Foot Asphalt Shingle Moount & Hanger BoltOptional
Cable Clip & Tie Optional
Ground Clip & Lugs Optional
| Components | SP3KW-HY | SP3.7KW-HY | SP4.6KW-HY | SP5KW-HY |
| 280W Mono Solar Panel | 12 Piece | 14 Piece | 18 Piece | 20 Piece |
| Dc Disconnect Switch | 1 Piece | 1 Piece | 2 Piece | 2 Piece |
| Hybrid Inverter | X1-HYBRID-3.0T | X1-HYBRID-3.7T | X1-HYBRID-4.6T | X1-HYBRID-5.0T |
| Triple Power Battery | 4.5 kWh | 4.5 kWh | 6.3 kWh | 6.3 kWh |
| Dc Cable 4mm2 | 100 meter | 100 meter | 200 meter | 200 meter |
| AC Disconnect Switch | 1 Piece | 1 Piece | 1 Piece | 1 Piece |
| MC4 Connector | 10 | 10 | 15 | 15 |
| Mounting System | Standards Pitched Roof ( Customized Optional) | |||
| PV Tools | 1 Set | |||
1. Q: Are you a factory or a trading company?
A: We are a professional Solar Panels Manufacturer in China
2. How can we guarantee the quality of the product?
A: Always provide the favored buyer with a pre-production sample before mass production; Always test every product before despatching the shipments;
3. What products we can supply you?
A: Solar panels, inverter, controller, cable, support frame, and other solar power systems
4. Q: Can the product's pricing be cheaper?
A: Of course, you will be offered a very good discount with large quantities.
5.. Q: Can print our company's logo on the PV panels?
A: Yes! And we accept OEM&ODM orders.
