12V 24V 48V MPPT Solar Inverter Hybrid On Off Grid Inverter Pure Sine Wave

  • 12V 24V 48V MPPT Solar Inverter Hybrid On Off Grid Inverter Pure Sine Wave
  • 12V 24V 48V MPPT Solar Inverter Hybrid On Off Grid Inverter Pure Sine Wave
  • 12V 24V 48V MPPT Solar Inverter Hybrid On Off Grid Inverter Pure Sine Wave
  • 12V 24V 48V MPPT Solar Inverter Hybrid On Off Grid Inverter Pure Sine Wave
  • 12V 24V 48V MPPT Solar Inverter Hybrid On Off Grid Inverter Pure Sine Wave
  • 12V 24V 48V MPPT Solar Inverter Hybrid On Off Grid Inverter Pure Sine Wave
Certification ISO, CE

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Model NO. HT-M2000 Application Home, Industrial, Commercial
Specification Normal, 270W*433H*105D(mm) The Working Environment Humidity En61000-6-1:2007: En61000-6-3:2007
Safety Gauge / EMC Standard IEC62109-1 / -2: As3100; Nb / T32004 Grid-Connected Standards En50438,G83/2as4777VDE0126-1-11ec61727,Nb/T320040~
Design Working Year > 20 Years Display Screen LCD, 2X20z
Communication Interface RS485.WiFi/GPRS (Optional) AC Port IP67 Protection Class Connector
DC Port Original Factory Mc4 Supporting Terminal Noise (Typical) <30 Dba
Protection Level IP65 The Highest Working Elevation 4000 Meters
Cooling Way Natural Convection Self Consumption <1W (Night)
The Working Environment Temperature 25c~60c Topology Without A Transformer
Transport Package Wooden Box Trademark Htonetech
Origin China Supply Ability 50000pieces/Year
Shipping Cost To Be Negotiated| Freight Cost Calculator After-sales Service Yes
Warranty 3year Condition New
High Light

24V MPPT Solar Inverter

,

12V MPPT Solar Inverter

,

48V Hybrid On Off Grid Inverter
Leave a Message
Product Description

Solar Power Inverter 3kw 12V 24V 48V Pure Sine Wave Inverter for Home Energy Syste Used for New Energy

Product Description

FEATURES

  • Power Output: The power output of the inverter should be sufficient to meet the energy needs of your home or business. You can determine this by looking at the size of your solar panel array and the energy consumption of your appliances.
  • Efficiency: The efficiency of the inverter is an important factor in maximizing the energy output of your solar panels. Look for an inverter with a high efficiency rating, as this will help to minimize energy losses.
  • Monitoring: A good solar power inverter should have monitoring capabilities that allow you to track the performance of your solar panels and the energy output of the inverter. This can help you identify any issues or inefficiencies in your system.
  • Durability: The inverter should be built to withstand the elements and last for many years. Look for an inverter with a sturdy construction and a good warranty.



APPLICATIONS:

  • Residential Solar Power Systems: Solar power inverters are commonly used in residential solar power systems to convert the DC electricity produced by solar panels into AC electricity that can be used to power appliances and devices in homes.
  • Commercial Solar Power Systems: Solar power inverters are also used in larger commercial solar power systems to convert the DC electricity produced by solar panels into AC electricity that can be used to power industrial and commercial applications.
  • Off-Grid Power Systems: Solar power inverters are essential components of off-grid solar power systems, which are designed to provide electricity to remote locations that are not connected to the grid.
  • Grid-Tied Power Systems: In grid-tied solar power systems, solar power inverters are used to convert the DC electricity produced by solar panels into AC electricity that can be fed back into the grid.



Solar Power Inverter 3kw 12V 24V 48V Pure Sine Wave Inverter for Home Energy Syste Used for New Energy GenerationSolar Power Inverter 3kw 12V 24V 48V Pure Sine Wave Inverter for Home Energy Syste Used for New Energy GenerationSolar Power Inverter 3kw 12V 24V 48V Pure Sine Wave Inverter for Home Energy Syste Used for New Energy Generation

MODEL HT-M700 HT-M1000 HT-M1500 HT-M2000 HT-M2500 HT-3K-2G-ST HT-3.6K-2G-ST HT-5K-2G HT-10K HT-15K HT-20K-HV HT-40K-HV
New energy power generation mode   photovoltaic power generation
input
Max input power  900 watt 1.2KW 1.8KW 2.4KW 3.0KW 3.5KW 4.2kw 5.8kw 11.5kw 16.5kw 20kw 45kw
Maximum input voltage   450V 500v 500v 600V 1000v
starting voltage       60V 600V 330v 350v
The MPPT voltage range  50-400V 100-500V 200-800v
Maximum input current  10A 18A 15A+15A 18A+18A 18A+18A+18A+18A
Quaintity of MPP / maximum input path  1/1 1/2 2/2 2/4 4/8
output
Rated output power  0.7kw 1KW 1.5KW 2KW 2.5KW 3KW 3.6kw 5kw 10kw 15kw 20kw 40kw
Max output power  0.8kW 1.1KW 1.65KW 2.2KW 2.5KW 3.3KW 4kw 5kw 11kw 15kw 20kw 40kw
Rated power grid voltage  220 / 230V 380v/400v 480v 480v
Grid voltage range from  180 to 270 V (adjustable) 313-470v(adjustable) 384-576v(adjustable)
Rated power grid frequency  50 / 60Hz
Grid phase single-phase three-phase
Maximum output current   4.4A 6.1A 9.2A 12.2A 13.9A 15.7A 16A 23.8A 16.7A 25A 25A 48.1A
Output power factor  0.8 ahead...0.8 lag
Maximum measured flow harmonic  TotalTHD <3%
The DC component value of the power grid   <20 mA
Operating frequency range of  47-52Hz or 57-62Hz (adjustable)
Operating frequency range of  47-52Hz or 57-62Hz (adjustable)
The maximum efficiency  96.70% 97.50% 97.80% 98.30% 98.60%
The European efficiency  96.20% 96.80% 97% 97.50% 98.30%
The MPPT efficiency was  99.90%
Protection
DC backconnection protection YES
Communication short circuit protection YES
AC-output overcurrent protection YES
Output overvoltage protection YES
Protection of insulation impedance YES
Residual current (RCD) detection YES
surge protection YES
Grid-connected monitoring YES
Island protection YES
Temperature protection YES
The Integrated DC switch selectable
Basic parameter
Size  270W*433H*105D(mm) 339W*585H*172.5D(mm) 430W*613H*269D(mm) 530W*700H*356.5D(mm)
Weight            5.2kg 13.8KG 30kg 58.2kg



ABOUT US:

Huatong Yuanhang (Beijing) Technology Development Co., Ltd.

Is a high-tech certified enterprise established in 2008, located in Beijing Zhongguancun Jinqiao Science and Technology Industrial Park. By insisting on the development idea of combining low-carbon, wisdom and technology, we have become the innovator of solar/wind complementary power system solutions.

Huatong Yuanhang focuses on providing high-quality power solutions for industrial customers, and its business is widely involved in the fields of army, transportation, security, petroleum, electric power, water conservancy, communication, forestry, agriculture, border defense and the three system operators of China network(Mobile, Unicom and Telecom). The solutions are widely provided to many countries in Latin America, Africa and Southeast Asia.

Huatong Yuanhang provides off-grid power supply systems for domestic and foreign provinces and cities without electricity through wind and solar complementary power supply systems, solar power supply systems, small and medium-sized photovoltaic power plants and distributed photovoltaic products.



FAQ

1. Q: Are you a factory or a trading company?
A :We are a professional Solar Panels Manufacturer in China

2.How can we guarantee the products quality?
A :Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;

3.What products we can supply you?
A :Solar panels,inverter,controller,cable,support frame and other solar power systems

4. Q: Can the products pricing be cheaper?
A :Of course, you will be offered a a very good discount with large quantities.

5.. Q: Can print our company's logo on the pv panels?
A :Yes! And we accept the OEM&ODM orders.
