SunPhoton-SunGlow-R290-Heat Pump PVT Europe

SunPhoton-SunGlow-Heat Pump-Europe

(NO German BAFA Certificate)

1. Basic Document Information

• Product Line: SUNGLOW SERIES R290 DC Inverter Space Heating & Cooling Monobloc Heat Pump
• Brand: SunPhoton
• Slogan: Warm your life with silent tech
• europe@pvsolarpowersystem.com/xiaaimin@pvsolarpowersystem.com
• www.pvsolarpowersystem.com

2. Core Eco & Energy-Saving Highlights

2.1 Low-Carbon R290 Natural Refrigerant

Adopts eco-friendly R290 refrigerant with GWP far below 20, extremely low greenhouse effect and no ozone depletion. R290 delivers higher heat exchange efficiency than traditional refrigerants, cutting long-term operating carbon emissions.

2.2 Top ErP Energy Rating

Fully complies with EU ErP directives:

• A+++ energy efficiency grade under 35°C water outlet condition
• A++ grade under 55°C water outlet condition

Greatly reduces household electricity consumption for heating/cooling/domestic hot water.

2.3 Full DC Inverter Constant Temperature Technology

Compared with traditional on/off fixed-speed heat pumps:

• Faster heating response, shorter waiting time for target temperature
• Tiny water temperature fluctuations, stable indoor thermal comfort
• Stable continuous operation at ambient temperature as low as -25°C
• Maximum hot water outlet temperature reaches 75°C, compatible with high-temp radiators, floor heating and fan coils

2.4 Smart Grid (SG Ready) Function

Supports linkage with photovoltaic solar systems and grid peak-valley power logic:

Automatically adjust unit operating status to consume surplus PV power and utilize off-peak cheap grid electricity, maximizing power cost savings.

3. Whole-House Integrated System Solution

3.1 Multi-Source Hybrid Compatibility

The unit can interlock with auxiliary heating sources (electric heater, solar collectors) to realize three functions in one machine: space heating, space cooling and domestic hot water (DHW).

3.2 Dual-Zone Precise Temperature Control

Supports two independent heating zones (e.g. floor heating zone + radiator/fan coil zone) matched with room thermostats for separate temperature regulation in different living areas.

3.3 Complete System Installation Diagram

The brochure provides full piping schematic including solar collectors, auxiliary heat source, buffer tank, three-way solenoid valves, mixing pumps, floor heating loops, fan coils, radiators and DHW storage tank, supporting both new house installation and old water pipeline renovation.

4. Multi-Dimensional Low-Noise Design

SunPhoton optimizes 6 core mute structures to eliminate running noise disturbance:

1. DC inverter low-vibration compressor
2. DC brushless silent fan motor
3. Aerodynamically optimized special fan blades
4. Shock-absorbing base plate for the whole unit
5. High-density sound-absorbing cotton inside the cabinet
6. Optimized turbulence air grille & shock-resistant pipeline layout

Sound pressure level at 1m ranges from 39~56dB(A) across all models, suitable for residential backyard/sidewall outdoor installation.

5. Premium Core Component Configuration

All key parts adopt well-known global brands for stable long-term operation:

1. DC Inverter Compressor: High-efficiency rotary compressor series (WHP models) with stable heating capacity and low vibration
2. DC Circulation Pump: Silent branded pump (GPA series), built inside the unit to simplify piping
3. Plate Heat Exchanger: Large heat exchange area, high COP & EER, low water pressure loss
4. Built-In Expansion Tank: Optional 2L / 5L capacity to stabilize the whole water system, reduce extra accessories for installation

6. Intelligent IoT Control System

6.1 4-inch Color Touch Wired Controller

High-definition intuitive interface, supports multi-mode switching: Heating / Cooling / DHW / Heating+DHW / Cooling+DHW / Mute / Timing / Electric heater activation / Heating curve setup. Real-time water outlet temperature display and equipment fault prompt.

6.2 WIFI & E-Home Mobile APP Remote Access

Built-in WIFI module enables full remote management via mobile phone anywhere:

• Real-time running data monitoring
• Historical energy consumption record statistics
• Remote mode switching & temperature adjustment
• Fault alarm push notification

7. Complete Model Range & Technical Specifications

7. Model Coverage

Heating capacity range: 6kW ~ 20kW, split into single-phase 220V and three-phase 380V variants, single-fan / double-fan outdoor units available, model codes:

60HCR5INVM, 90HCR5INVM, 130HCR5INVM, 160HCR5INVM, 90HCR5TINVM, 130HCR5TINVM, 160HCR5TINVM, 185HCR5TINVM, 200HCR5TINVM

7. Key Performance Data (3 Test Standards)

1. Space Heating (7°C ambient, 30/35°C water)

COP up to 4.35, SCOP reaches A+++/A++ EU standard, heating output 6~22.83kW.

2. Space Cooling (35°C ambient, 12/7°C chilled water)

EER range 2.90~4.63, cooling capacity 1.8~16.2kW for different models.

3. Domestic Hot Water (20°C ambient, heat water from 15°C to 55°C)

Hot water COP stable above 4.24, max hot water production up to 22.69kW.

7. Other Standard Parameters

• Operating ambient range: -25℃ ~ +43℃
• Max outlet water temp: 75℃
• Refrigerant: R290, filling volume 0.65~1.65kg
• Waterproof grade: IPX4, electric shock protection Class Ⅰ
• Water pipe connection: G1 1/4"
• Net weight: 84kg ~ 180kg, unit dimension: 1180/1263 × 440 × 710/875/1375mm
• CO2 equivalent per unit as low as 0.0019 ton, ultra-low carbon footprint

8. Product Positioning & Application Scenarios

Sunglow Series is SunPhoton’s entry-level mainstream residential monoblock heat pump, positioned for cost-sensitive ordinary apartments, villas and rural residential projects:

• Advantage balance: Affordable price while retaining full DC inverter, R290 low-carbon refrigerant, WIFI smart control and -25°C low-temperature heating capacity
• Applicable terminal heating equipment: Underfloor heating, wall-mounted radiators, ceiling fan coils
• Global market target: European, Australian, North American mass residential retail & small contractor renovation projects

9. Document Structure Logic

1. Cover & brand contact information
2. R290 refrigerant & ErP energy label introduction
3. Whole-house hybrid system installation schematic
4. SG smart grid & full DC inverter temperature stability principle
5. Low-noise structural design and core component introduction
6. 4-inch touch controller & WIFI IoT function display
7. Full table of electrical, thermal, dimensional specifications for all models
8. Parameter test condition notes and disclaimer

The datasheet focuses on cost-effective residential demand, highlighting basic three-in-one comfort, low-carbon refrigerant and user-friendly intelligent control, distinguishing it from the high-end Hi-Master V Series with more simplified indoor hydraulic modules and lower overall cost.

This is NO German BAFA Certificate.
