5KW 10KWH Energy Storage System DEYE SUN-5K-SG05LP1-EU-SM2-P SE-G10.2

Large Image : 5KW 10KWH Energy Storage System DEYE SUN-5K-SG05LP1-EU-SM2-P SE-G10.2

Product Details:

Place of Origin:	CHINA
Brand Name:	DEYE
Model Number:	SUN-5K-SG05LP1-EU-SM2-P/SE-G10.2

Payment & Shipping Terms:

Minimum Order Quantity:	1unit
Price:	USD 1990
Delivery Time:	45-90 workdays
Payment Terms:	T/T

Contact Now chat now

Detailed Product Description

Max Charge Current:

100A (continuous), 200A (peak 10s)

Max Discharge Current:

100A (continuous), 200A (peak 10s)

Cycle Life:

≥6000 Cycles (25°C, 0.2C, 80% DOD)

Dimensions:

710 × 540 × 133 Mm

Highlight:

5KW energy storage system

10KWH energy storage system

100A battery energy storage system

DEYE 5KW/10KWH SUN-5K-SG05LP1-EU-SM2-P/SE-G10.2

Product Description

The DEYE 5KW / 10KWH energy storage system combines a high-efficiency single-phase hybrid inverter with a 10.24KWh LiFePO4 battery, providing reliable residential and small commercial solar energy storage solutions. The system supports grid-tied, off-grid, and hybrid operation modes, enabling efficient energy utilization, peak shaving, and backup power supply.

With advanced MPPT technology, wide PV input range, and intelligent battery management, it ensures stable performance, high efficiency, and long service life for residential solar energy systems.

System Composition

Hybrid Inverter: SUN-5K-SG05LP1-EU-SM2
Battery System: DEYE SE-G10.2 (10.24KWh LiFePO4)
Optional Monitoring System (Wi-Fi / App)
PV Array Integration System
Smart Energy Management System (EMS Ready)

Hybrid Inverter Specifications (SUN-5K-SG05LP1-EU-SM2)

Battery Input Data

Item	Specification
Battery Type	Lithium-ion / Lead-acid
Battery Voltage Range	40–60V
Max Charge Current	120A
Max Discharge Current	120A

PV Input Data

Item	Specification
Max PV Input Power	8000W
Max PV Access Power	10000W
Max PV Input Voltage	500V
MPPT Voltage Range	150–425V
MPPT Trackers	2 (1+1 configuration)

AC Output Data

Item	Specification
Rated Power	5000W
Max Apparent Power	5500VA
Rated Voltage	220V / 230V
Grid Connection	L + N + PE
Rated Current	22.8A / 21.8A

Efficiency & Protection

Max Efficiency: 97.6%
Euro Efficiency: 96.5%
MPPT Efficiency: >99%
DC Reverse Polarity Protection
AC Overcurrent / Overvoltage Protection
Short Circuit Protection
Thermal Protection
Anti-islanding Protection
Arc Fault Protection (optional)
IP65 Protection Rating
Operating Temperature: -40°C to +60°C

Battery System Specifications (SE-G10.2)

Item	Specification
Battery Type	Lithium Iron Phosphate (LiFePO₄)
Nominal Capacity	200Ah
Nominal Voltage	51.2V
Energy Capacity	10.24kWh
Recommended DOD	80%
Max Charge Current	100A (continuous), 200A (peak 10s)
Max Discharge Current	100A (continuous), 200A (peak 10s)
Cycle Life	≥6000 cycles (25°C, 0.2C, 80% DOD)
Dimensions	710 × 540 × 133 mm
Weight	~85 kg

System Features

5KW High-Efficiency Hybrid Solar System
10.24KWh Reliable LiFePO4 Energy Storage
High MPPT Efficiency (>99%) for Maximum Solar Utilization
Wide PV Input Range for Flexible System Design
Intelligent Battery Management System (BMS)
Multiple Protection Mechanisms for Safe Operation
Grid-Tied and Off-Grid Operation Capability
Smart Monitoring via Wi-Fi / App (Optional)
Compact and Easy Installation Design
Long Cycle Life (≥6000 Cycles)
