5KW Solar Power System With 10Kwh Battery And 5 KW Inverter For Reliable Photovoltaic Energy

5KW Solar Power System With 10Kwh Battery And 5 KW Inverter For Reliable Photovoltaic Energy
5KW Solar Power System With 10Kwh Battery And 5 KW Inverter For Reliable Photovoltaic Energy 5KW Solar Power System With 10Kwh Battery And 5 KW Inverter For Reliable Photovoltaic Energy

Large Image :  5KW Solar Power System With 10Kwh Battery And 5 KW Inverter For Reliable Photovoltaic Energy

Product Details:
Place of Origin: China
Brand Name: Sun Photon
Certification: CE
Model Number: SPWB5KW10kwh
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD+4900+Set
Delivery Time: 5-30 working days
Payment Terms: T/T
Supply Ability: 10000+Set+per Month
Detailed Product Description
Solar Panel Capacity: 5KW Solar Panel Type: High-efficiency Monocrystalline PV Modules
Inverter Capacity: 5KW Inverter Type: Hybrid / Off-grid Solar Inverter
Highlight:

5KW Solar Panel Solar Power System

,

10Kwh Battery Solar Power System

,

5 KW Inverter Photovoltaic System

5KW Solar Power System With 10Kwh Battery And 5 KW Inverter For Reliable Photovoltaic Energy



Product Description

This complete 5KW solar power system is a reliable photovoltaic energy solution designed for residential and small commercial applications. It integrates solar power generation, energy conversion, and battery storage into a single system, ensuring stable and continuous electricity supply.

The system includes high-efficiency solar panels, a 5KW inverter, a 10KWH lithium battery storage unit, and a full Balance of System (BOS) package. It is ideal for on-grid, hybrid, or off-grid installations, helping users reduce electricity costs and improve energy independence



Product Specifications

Item Specification
Product Name 5KW Solar Power System with 10KWH Battery and 5KW Inverter
Solar Panel Capacity 5KW
Solar Panel Type High-efficiency Monocrystalline PV Modules
Inverter Capacity 5KW
Inverter Type Hybrid / Off-grid Solar Inverter
Battery Capacity 10KWH
Battery Type LiFePO4 Lithium Battery
Nominal Voltage 48V / 51.2V
System Output Voltage 220V / 230V / 240V
Frequency 50Hz / 60Hz
Communication RS485 / CAN
Battery Cycle Life ≥6000 Cycles
Protection System Intelligent BMS (Battery Management System)
Monitoring System Smart Remote Monitoring (Optional)
BOS Components Mounting structure, cables, combiner box, breakers, connectors
Installation Type Roof-mounted / Ground-mounted
Operating Temperature -20°C ~ 60°C
Protection Level IP54 / IP65 (Battery System)
System Type On-grid / Off-grid / Hybrid Solar System
Expandability Support parallel battery expansion
Application Residential & Small Commercial Energy Storage
Warranty 5–10 Years



System Components

  • 5KW Solar Panel Array: High-efficiency photovoltaic modules designed to maximize solar energy generation.
  • 5KW Inverter: Converts DC power generated by solar panels into usable AC electricity for household or commercial use.
  • 10KWH Battery Storage: Lithium energy storage system that stores excess solar power for nighttime use and backup during outages.
  • BOS (Balance of System): Includes mounting structures, cables, protection devices, junction boxes, and all necessary installation accessories for a complete system setup.

Product Features

  • High-Efficiency Solar Power Generation System
  • Integrated Energy Storage Solution
  • Reliable LiFePO4 Battery Technology
  • Stable and Continuous Power Supply
  • Smart Energy Management Capability
  • Suitable for Hybrid, On-Grid, and Off-Grid Use
  • Complete Turnkey System Design
  • Easy Installation and Maintenance
  • Eco-Friendly Renewable Energy Solution

Applications

  • Residential Solar Power Systems
  • Small Commercial Buildings
  • Villas and Apartments
  • Rural and Off-Grid Areas
  • Backup Power Systems
  • Farms and Agricultural Facilities
  • Small Offices and Shops
  • Renewable Energy Projects
