800W Microinverter LS-800Mi For Residential Small Commercial Photovoltaic Systems

800W Microinverter LS-800Mi For Residential Small Commercial Photovoltaic Systems
800W Microinverter LS-800Mi For Residential Small Commercial Photovoltaic Systems

Large Image :  800W Microinverter LS-800Mi For Residential Small Commercial Photovoltaic Systems

Product Details:
Contact Now chat now
Detailed Product Description
Operating Temperature: -40°C ~ +65°C Dimensions: 260 × 225 × 32 Mm
Weight: 2.9 Kg Warranty: 10 Years
Highlight:

800W microinverter

,

280W microinverter

,

550W micro inverter solar

800W Microinverter LS-800Mi



Product Description

The LS-800Mi 800W Microinverter is a high-efficiency, module-level solar power conversion device designed for residential and small commercial photovoltaic systems. It provides safe low-voltage DC operation with a maximum 60V input, significantly reducing installation risks while maintaining high energy conversion efficiency.

With dual MPPT technology, IP67 protection, and intelligent WiFi monitoring, the LS-800Mi ensures stable performance, real-time data tracking, and reliable operation in harsh environmental conditions. Its compact and lightweight design makes it ideal for small-scale solar installations and distributed energy systems.



Product Specifications

DC Input

Item

Specification

Recommended PV Module Power

280W – 550W

Start-up Voltage

20V

MPPT Voltage Range

25V – 55V

Maximum Input Voltage

60V

Maximum Input Current

13.5A × 2

Maximum Short Circuit Current

16.5A × 2

MPPT Channels

2



AC Output

Item

Specification

Rated Output Power

800W

Rated Output Voltage

230V

Rated Output Current

3.47A

Frequency Range

50Hz ±5Hz

Peak Efficiency

96%

Static MPPT Efficiency

99.5%



Mechanical & Environmental

Item

Specification

Operating Temperature

-40°C ~ +65°C

Dimensions

260 × 225 × 32 mm

Weight

2.9 kg

Protection Rating

IP67

Cooling Method

Natural convection (fanless)

Communication

WiFi

Warranty

10 Years



Product Features

  • Safe 60V Low-Voltage DC Design for Enhanced Safety

  • Dual MPPT Technology for Maximum Energy Harvesting

  • High Conversion Efficiency up to 96%

  • IP67 Waterproof and Dustproof Protection

  • Compact and Lightweight Design for Easy Installation

  • Full Metal Housing with Efficient Heat Dissipation

  • Smart WiFi Monitoring for Real-Time Energy Tracking

  • Instant Fault Detection and System Alerts

  • Wide Temperature Range (-40°C to +65°C)

  • Suitable for Residential and Small Business Use



Applications

  • Residential Rooftop Solar Systems

  • Small Commercial PV Installations

  • Balcony and Distributed Solar Systems

  • Smart Home Energy Systems

  • Small Office and Retail Energy Supply

  • Modular and Expandable Solar Projects

  • Complex Roof and Shaded Installations
