SunPhoton-All-in-one-YF-11KW-28KWh BESS+Hybrid Inveter

Large Image : SunPhoton-All-in-one-YF-11KW-28KWh BESS+Hybrid Inveter

Product Details:

Place of Origin:	Made By China
Brand Name:	SunPhoton
Certification:	CE
Model Number:	SP-AIO-YF-11KW-28KWH (dfd)

Payment & Shipping Terms:

Minimum Order Quantity:	MOQ to contact sales
Price:	FOB or DAP/DDP to contact sales
Packaging Details:	Different packaging methods are adopted according to different modes of transport.
Delivery Time:	5-30 working days
Payment Terms:	T/T
Supply Ability:	10000+Set+per Month

Contact Now chat now

Detailed Product Description

Highlight:

11kw hybrid inverter

28KWh all in one inverter

BESS all in one inverter

Model: SP-AIO-YF-11KW-28KWh (dfd)
Battery Capacity: 28kWh (560Ah / 51.2V)
Rated Power: 11000W / Peak 22000VA
Cycle Life: ≥ 6000 cycles
Cell Type: Lithium Iron Phosphate (LFP)
AC Input: 195-253VAC ±3V
AC Output: 220/230/240VAC ±5%
Rated Battery Input Voltage: 48V DC
PV Input Power: 5500W × 2 channels MAX
MPPT Voltage Range: 90-500VDC
MPPT Max Input Voltage: 500VDC MAX
AC Input Current: 150A MAX
DC Output: 12V 3A / USB: 5V 2.4A / TYPE-C: 5V 2.4A
Supported Functions: WIFI (optional), LCD display
Overall Dimensions: 708.8×550×903mm (including one battery pack: 708.8×550×260mm, 110kg)
Wooden Case Dimensions: 1000×780×1030mm
Net Weight: 275kg; Gross Weight: 310kg
20ft Container Loading Qty: 28 units
40ft Container Loading Qty: 60 units
