Photovoltaic Solar Pv Battery Storage Gel Deep Cycle Battery 12V 200ah

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Supply Ability 50000pieces/Year Discharge Rate Low Discharge Rate
Shape Square Battery Electrolyte Acid
Installation Packaged Rechargeable Chargeable
Storage Temperature -20~40ºC Fields Of Application Street Lights, Surveillance, UPS, Off-Grid Systems
Discharge Temperature -40~50ºC Charging Temperature -0~45ºC(Heating Plate Optional)
Transport Package Wooden Box Specification 483x170x240(mm)
Trademark Htonetech Origin China
Shipping Cost To Be Negotiated| Freight Cost Calculator Type Lead-Acid Batteries
Usage Electric Power, Solar Nominal Voltage 12V
High Light

Photovoltaic Solar Pv Battery Storage

,

Gel Deep Cycle Battery 200ah

,

Gel Deep Cycle Battery 12V

Leave a Message
Product Description

Gel Cell Solar Cell Energy Storage High Capacity 12V 200ah Photovoltaic off Grid Power Generation System

Product Description

A gel deep cycle battery is a type of rechargeable battery commonly used for solar PV (photovoltaic) battery storage systems. It is specifically designed to provide sustained power over extended periods, making it well-suited for applications that require deep cycling, such as solar energy storage.

Here are some key points about gel deep cycle batteries for solar PV battery storage:

  1. Deep cycle capability: Gel deep cycle batteries are designed to withstand repeated deep discharges and recharges. They can consistently deliver power over extended periods, making them suitable for solar PV battery storage applications where the battery is frequently cycled.
  2. Gel electrolyte: Unlike traditional flooded lead-acid batteries, gel deep cycle batteries use a gel electrolyte rather than a liquid electrolyte. The gel electrolyte is highly viscous and immobilized, preventing acid stratification and enhancing the battery's resistance to vibration and shock.
  3. Maintenance-free: Gel deep cycle batteries are often considered maintenance-free. The gel electrolyte does not require regular watering or checking of electrolyte levels, making them more convenient and easier to manage.
  4. Enhanced safety: Gel batteries are generally considered safer compared to flooded lead-acid batteries. The gel electrolyte is non-spillable, which reduces the risk of acid leaks or spills. This makes them suitable for indoor applications and areas where safety is a concern.
  5. Slow self-discharge rate: Gel deep cycle batteries have a relatively slow self-discharge rate, which means they can retain their charge for longer periods without requiring frequent recharging. This is beneficial for solar PV systems that may have periods of low sunlight or limited solar energy generation.
  6. Limited off-gassing: Gel batteries have limited off-gassing compared to flooded lead-acid batteries. This means they produce fewer corrosive gases during charging, making them suitable for applications where ventilation may be limited.

Gel Cell Solar Cell Energy Storage High Capacity 2V 250ah Photovoltaic off Grid Power Generation SystemGel Cell Solar Cell Energy Storage High Capacity 2V 250ah Photovoltaic off Grid Power Generation System

12V 80A 25.5KG 6.2mΩ 20.0A -35~60ºC 329 172 214 236 ABS
100A 28.6KG 5.3mΩ 25.0A 329 172 214 236
150A 42.2KG 4.0mΩ 37.5A 483 170 240 240
200A 58.3KG 3.3mΩ 50.0A 522 240 219 244
250A 69.3KG 2.9mΩ 62.5A 520 269 220 245
2V 100Ah 5.5KG 0.85mΩ 25A 170 76 214 223
200Ah 13.3KG 0.66mΩ 50A 171 106 330 342
250Ah 16.6kg 0.56mΩ 62.5A 171 151 330 342
300Ah 18.4kg 0.46mΩ 75A 171 151 330 342
400Ah 23.6KG 0.41mΩ 100A 196 171 330 342
600Ah 35.2KG 0.31mΩ 150A 285 171 330 342
800Ah 48.2kg 0.23mΩ 200A 383 171 330 342
1000Ah 58.3kg 0.21mΩ 250A 471 171 330 342
1500Ah 84.9kg 0.17mΩ 375A 318 341 341 351
2000Ah 114.6kg 0.14mΩ 500A 433 342 341 351
2500Ah 160.8kg 0.13mΩ 625A 629 346 341 351
3000Ah 170.9kg 0.11mΩ 750A 329 346 341 351
Rated Voltage Rated Capacity Approximate Weight Internal Resistance Maximum Charge Current Ambient Temperature Length Width Height Total Height Case
Gel Cell Solar Cell Energy Storage High Capacity 2V 250ah Photovoltaic off Grid Power Generation SystemGel Cell Solar Cell Energy Storage High Capacity 2V 250ah Photovoltaic off Grid Power Generation SystemGel Cell Solar Cell Energy Storage High Capacity 2V 250ah Photovoltaic off Grid Power Generation SystemGel Cell Solar Cell Energy Storage High Capacity 2V 250ah Photovoltaic off Grid Power Generation System

FAQ

1. Q: Are you a factory or a trading company?
A :We are a professional Solar Panels Manufacturer in China

2.How can we guarantee the products quality?
A :Always provide the esteemed buyer a pre-production sample before mass production; Always testing every product before despatching the shipments;

3.What products we can supply you?
A :Solar panels,inverter,controller,cable,support frame and other solar power systems

4. Q: Can the products pricing be cheaper?
A :Of course, you will be offered a a very good discount with large quantities.

5.. Q: Can print our company's logo on the pv panels?
A :Yes! And we accept the OEM&ODM orders.
