SP P05-U7 7kW PV +8 kW Hybrid Inverter +10kWh LFP Off Grid Kit

Large Image : SP P05-U7 7kW PV +8 kW Hybrid Inverter +10kWh LFP Off Grid Kit

Product Details:

Place of Origin:	China
Brand Name:	Sun Photon
Certification:	CE
Model Number:	P05

Payment & Shipping Terms:

Minimum Order Quantity:	1 Container
Price:	FOB or DAP/DDP to contact sales
Packaging Details:	Different packaging methods are adopted according to different modes of transport.
Delivery Time:	5-30 working days
Payment Terms:	T/T
Supply Ability:	10000+Set+per Month

Contact Now chat now

Detailed Product Description

Highlight:

7kW PV System

8kW Hybrid Inverter

10kWh LFP Battery

Config Code	PV Module	Inverter	Battery	Pcs PV/set	kWp
Config‑1	LONGi 655W	GoodWe GW8000‑ES‑C10	GoodWe 10.24kWh	12	7.86
Config‑2	LONGi 655W	GoodWe GW8000‑ES‑C10	Deye 10.64kWh	12	7.86
Config‑3	LONGi 655W	Deye SUN‑8K‑SG05LP1‑EU‑SM2	Deye 10.64kWh	12	7.86
Config‑4	AIKO 665W	GoodWe GW8000‑ES‑C10	GoodWe 10.24kWh	11	7.315
Config‑5	AIKO 665W	GoodWe GW8000‑ES‑C10	Deye 10.64kWh	11	7.315
Config‑6	AIKO 665W	Deye SUN‑8K‑SG05LP1‑EU‑SM2	Deye 10.64kWh	11	7.315

Product Specifications & Compatibility Confirmation

Category	Brand / Model	Key Specifications	Warranty
PV Module (Option A)	LONGi Hi-MO X10 LR7-72HT-655W	655W, N-type HPBC bifacial, 24.8% efficiency, 12 pcs/set = 7.86 kWp	15-year product + 30-year linear performance
PV Module (Option B)	AIKO Comet 3N72 AIKO-A665-MAH72DW	665W, N-type ABC back-contact, 24.9% efficiency, 11 pcs/set = 7.315 kWp	15-year product + 30-year linear performance
Hybrid Inverter	GoodWe GW8000-ES-C10 (ES Uniq)	8kW single-phase hybrid, 51.2V LV battery compatible, IP66, CAN-bus	5-year standard factory warranty
LFP Battery (Option 1)	GoodWe Lynx A LX-A10.2-10	10.24 kWh usable LFP, 51.2V, wall-mount, native CAN match for GW8000-ES	10-year product warranty
LFP Battery (Option 2)	Deye RW-G10.6	10.64 kWh usable LFP, 51.2V, wall-mount, CAN protocol adapted for GoodWe	10-year product warranty

▎Compatibility Confirmation
1. GoodWe Lynx A battery is factory-validated native match for GW8000-ES-C10 inverter; full warranty maintained.
2. Deye RW-G10.6 supports GoodWe CAN protocol; firmware will be pre-configured before shipment to guarantee stable interoperability.
3. Both battery options are 51.2V low-voltage LFP, electrically compatible with GoodWe ES-Uniq hybrid inverter.
4. PV modules (LONGi / AIKO) are standard string PV, compatible with all listed hybrid inverters regardless of brand.
5. All components carry CE/TUV certification for EU market customs clearance.
6. Per-set price includes standard mounting accessories, DC cables, connectors and packaging.

▎FOB Loading Port Recommendation
Preferred Port: Shanghai Port — highest vessel frequency, mature DG handling for LFP batteries, abundant carrier options.
Lowest-Cost Alternative: Ningbo-Zhoushan Port — lower terminal & trucking fees, less congestion, comparable global coverage.
No extra surcharge for switching between Shanghai and Ningbo-Zhoushan.
