SunPhoton SP-M2500RT Solar Robotic Mower
Cover
SunPhoton Photon Robotics SP-M2500RT Solar｜RTK Fusion Robotic Lawn Mower Optional 600W BC Solar Kit · Flagship Mainstream Model for Large Yards
Centimeter Precision, Extended Runtime, Integrated Solar & Energy Storage
Table of Contents
- Product Overview & Positioning
- Core Advantages vs Competitor ECOVACS A2500
- Navigation & Core Technology
- Specification Sheet
- Optional 600W BC Solar Charging Kit
- Smart APP & Energy Ecosystem Integration
- Safety, IP Rating & Certifications
- Standard Packing & Optional Accessories
- Recommended Markets & Channel Strategy
- Warranty Terms
1. Product Overview & Positioning
SP-M2500RT Solar is SunPhoton’s flagship mainstream robotic mower designed for global large residential yards, benchmarking ECOVACS A2500 RTK. Suitable for lawns from 2500㎡ up to 2800㎡. It adopts RTK + Dual 360° LiDAR + AIVI 3D vision fusion navigation to solve positioning drift under tree canopies and complex landscapes. The unit comes standard with an AC charging dock. The 600W BC solar charging kit is sold separately as an optional upgrade. Two customer segments are covered:
- EU & US grid-connected homes: use standard AC dock, direct competitor to A2500
- Off-grid villas, farms, Africa / emerging markets: add the 600W BC solar kit to reduce grid dependency and integrate with SunPhoton residential energy storage & BIPV systems.
Positioning: High-volume profit SKU for Amazon, independent store, DIY retailers and landscape & solar integrators.
2. Core Differentiation vs ECOVACS A2500
✅ Parity performance vs A2500 RTK centimeter positioning, dual LiDAR, AIVI 3D obstacle recognition, Zero‑Edge cutting, dual cutting discs, 2500㎡ large lawn capacity. ✅ Exclusive SunPhoton advantages
- Optional 600W BC back-contact solar kit: Mature BC module, excellent low-light performance, high continuous charging power for the dock, strong off-grid capability
- Energy storage open API: Connect with SunPhoton ESS & BIPV ecosystem; unified energy dashboard
- Max slope upgraded to 55% (A2500:50%), better performance on steep yards
- Pre-built cluster communication protocol: Single unit for home use; multiple units work in farm cluster mode with SunPhoton edge gateway
- Shared spare part pool with SunPhoton BC PV & ESS products, lower after-sales pressure for distributors.
Strategy note: Base version keeps balanced BOM structure to compete directly; 600W BC solar kit is a high-value upsell / bundle accessory for EPC and energy dealers.
3. Navigation & Core Technology
LELS 2.0 RTK Fusion Navigation System
- RTK differential positioning: Centimeter-level accuracy, multi-constellation GNSS, minimized drift under trees
- Dual 360° solid-state LiDAR: Real-time mapping, narrow path planning
- 150° AIVI 3D vision: Recognize 200+ yard obstacles (pets, pipes, roots, toys, leaf piles)
- Multi-zone maps, virtual boundary, multi-yard management, schedule planning
- Systematic parallel mowing path, auto obstacle avoidance, auto return to dock
4. Specification Sheet
表格
|
Item
|
SP-M2500RT Solar (Base Unit)
|
|
| Navigation |
RTK GNSS + Dual 360° LiDAR + AIVI 3D Vision Fusion |
|
| Recommended lawn area |
2500–2800 ㎡ |
|
| Max climbing slope |
55% |
|
| Cutting system |
Dual cutting discs, Zero‑Edge boundary cutting |
|
| Cutting width |
330 mm |
|
| Cutting height |
3–9 cm, electronically adjustable |
|
| Battery |
32V Li-ion pack |
|
| Continuous mowing time |
75 min |
Fast charge 45 min |
| IP Rating |
IPX6, light rain operation allowed |
|
| Communication |
Wi-Fi + Optional 4G module, OTA upgrade |
|
| Noise level |
≤58dB(A) |
|
| Unit weight |
24.5 kg |
|
5. Optional Solar Kit SKU: SP-SOL2500-600
- PV Module: SunPhoton standard BC back-contact module, 600W
- Controller: Integrated MPPT, anti-reverse, surge & overcharge protection
- Mounting: Galvanized ground bracket, installed near charging dock
- Function: Supply continuous solar power to charging dock in sunny hours; App shows real-time power & daily generation
- Target: Off-grid farms, remote villas, unstable-grid regions, solar + landscape turnkey packages
Sold separately, can be retrofitted anytime, ideal bundle item for solar EPC partners
6. Smart APP & Energy Integration
- SunPhoton Smart App (iOS / Android)
- Live map, working status, battery, alarm, remote start-stop, multi-schedule
- Solar dashboard after kit installed: generation & power consumption statistics
- Open API for SunPhoton ESS / BIPV: whole-yard energy management
- Anti-theft: tilt alarm, geofence, 4G alert
7. Safety & Certifications
- Blade stop on bump / lift safety sensor
- IPX6 water resistant (not submersible)
- Certifications: CE RED, LVD, EMC, FCC, RoHS, UKCA, California battery compliance
- Child lock function
8. Standard & Optional Accessories
✅ Standard: Main robot, AC charging dock, RTK antenna, power adapter, spare blades, installation toolkit, user manual ➕ Optional: SP-SOL2500-600 (600W BC Solar Kit), 4G module, spare battery, premium blade pack, extended warranty, anti-theft kit
9. Market & Channel
- Mature markets (DE / US / Poland): Push base unit, benchmark A2500; 600W BC solar kit for premium solar & landscape integrators
- Emerging markets (Tunisia, Nigeria, Benin): Bundle robot + 600W BC solar kit together with solar pump & ESS as off-grid yard energy package
- Channels: Amazon / Shopify DTC, OBI / Bauhaus DIY retail, professional garden dealers, solar EPC integrators
10. Warranty
Base robot: 2-year global warranty SP-SOL2500-600: 12-year linear power warranty for BC PV module, 2-year warranty for electronic controller Commercial farm: Optional paid 3-year extended warranty
Global Compliance CE RED, LVD, EMC, FCC, RoHS, UKCA, California battery compliance
