xName | 5 Blades 48vdc Solar Wind Turbine | Type | Hybrid Renewable Energy System |
---|---|---|---|
Keyword | Solar Wind Turbine | Body Material | Robust Aluminum Alloy |
Rated Power | 600w | Rated Voltage | 48VDC |
Quality Of Blades | 5 | Cut-in Wind Speed | 2.5m/s |
High Light | Solar Wind Turbine Flange Tower,48vdc Solar Wind Turbine,5 Blades Solar Wind Generator |
5 blades 48vdc solar wind turbine flange tower connection
product description of solar wind turbine
A solar wind turbine, also known as a hybrid wind-solar system, combines the power generation capabilities of both solar panels and wind turbines in a single system. This hybrid approach allows for increased energy production and a more reliable power supply, as it takes advantage of both solar and wind resources. Here are some key points about solar wind turbines:
Components: A solar wind turbine system typically includes solar panels, a wind turbine, a charge controller, an inverter, batteries, and the necessary wiring and mounting structures.
- Solar panels: Solar panels capture sunlight and convert it into electricity through the photovoltaic effect. They generate power during daylight hours, providing a steady source of energy.
- Wind turbine: The wind turbine consists of rotor blades and a generator. When wind blows, the rotor blades spin, converting the wind's kinetic energy into electrical energy through the generator. Wind turbines generate power even during low-light or nighttime conditions.
- Charge controller: The charge controller regulates the flow of electricity from the solar panels and wind turbine to the batteries. It ensures that the batteries are charged properly, protects them from overcharging or discharging, and optimizes the charging process.
- Inverter: The inverter converts the direct current (DC) electricity produced by the solar panels and wind turbine into alternating current (AC) electricity, which is suitable for powering household appliances and electronics.
product features of solar wind turbine
aesthetically pleasing
low starting wind speed
low running vibration
remarkable efficiency in converting wind energy
easy to install
solar wind turbine technical parameters
Model |
HY-600
|
|
Rated power (W) | 600 | |
Rated voltage (VDC) | 24 | 48 |
Max. power (W) | 750 | |
Start-up wind speed (m/s) | 2.0 | |
Cut-in wind speed (m/s) | 2.5 | |
Rated wind speed (m/s) | 12 | |
Survival wind speed (m/s) | 50 | |
Rotor diameter (m) | 1.75 | |
Quality of blades | 5 | |
Noise (dB) | < 20 dB (based on 5m/s wind speed) | |
Generator type | Three phase permanent magnet direct drive | |
Tower connection | Flange connection or bolt-on clamp | |
Net weight (kg) | 25 | |
Ambient temperature (°C) | -40~60 | |
Strong wind protection | Electromagnetic brake, aerodynamic brake | |
Dimensions | 1250×520×250mm | |
Weight | HY-600H (3 blades) net weight: 21kg; gross weight: 24kg | |
HY-600L (5 blades) net weight: 25kg; gross weight: 28kg |
