SunPhoton‑ENTRY Energy Storage with ca. 40% Margin for Channel Partners

Large Image : SunPhoton‑ENTRY Energy Storage with ca. 40% Margin for Channel Partners

Product Details:

Place of Origin:	China
Brand Name:	SunPhoton
Certification:	CE
Model Number:	SunPhoton‑ENTRY Energy Storage

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	FOB China
Packaging Details:	Different packaging methods are adopted according to different modes of transport.
Delivery Time:	5-30 working days
Payment Terms:	T/T
Supply Ability:	10000+Set+per Month

Contact Now chat now

Detailed Product Description

SunPhoton‑ENTRY Energy Storage | Specification Sheet

SunPhoton‑ENTRY Entry-level Home Energy Storage Chemistry: LFP Lithium Iron Phosphate Rated System Voltage: 51.2V Cycle Life: ≥4000 cycles @80% DOD, 25℃ Communication: CAN / RS485, Bluetooth & Wi-Fi for SunPhoton APP Certifications: UN38.3, CE-EMC, CE-LVD Cooling: Air Cooling Ambient Temp: Charge: 0~45℃; Discharge: -20~55℃ Application: Off-grid / Grid-tie backup, compatible with Solar PV & SunPhoton Entry Vertical Axis Wind Turbine

EP‑A Series | All-in-One (Battery + Built-in PCS Inverter, AC output directly)

Model	Nominal Capacity	Rated PCS Power	Output	Dimension	Weight	Target FOB Price(USD)	Key Features
EP-A-05	0.5kWh	500W	230V AC	320×220×280mm	12kg	145+	Portable with handle; for lighting, TV, small fridge; PV input support
EP-A-10	1kWh	1000W	230V AC	360×250×300mm	19kg	235+	Desktop portable; off-grid emergency power; support solar charging
EP-A-20	2kWh	2000W	230V AC	480×260×340mm	32kg	385+	Wall mounted; home basic backup; PV & mains charging
EP-A-30	3kWh	3000W	230V AC	520×280×360mm	42kg	545+	Wall mount; priority off-grid; hybrid PV/mains complementary
EP-A-50	5kWh	5000W	230V AC	600×300×380mm	58kg	920+	Best-selling entry home storage; hybrid on/off grid
EP-A-100	10kWh	5000W	230V AC	720×420×450mm	112kg	1840+	Stackable; main power supply for big family
EP-A-150	15kWh	6000W	230V AC	780×480×480mm	160kg	2560+	Stackable floor type; large family & small workshop backup
EP-A-200	20kWh	8000W	230V AC	860×520×500mm	205kg	3280+	Stackable; small commercial & villa power backup

EP‑B Series | Battery Pack Only (Without Inverter, External PCS required)

Model	Nominal Capacity	Spec	Communication	Dimension	Weight	Target FOB Price(USD)	Key Features
EP-B-05	0.5kWh	51.2V,10Ah	CAN+RS485	300×200×260mm	10kg	105+	Portable/wall mount; work with 3rd party hybrid inverter
EP-B-10	1kWh	51.2V,20Ah	CAN+RS485	340×220×280mm	16kg	175+	Small capacity expansion module
EP-B-20	2kWh	51.2V,40Ah	CAN+RS485	420×240×320mm	27kg	300+	Basic home energy storage module
EP-B-30	3kWh	51.2V,60Ah	CAN+RS485	480×260×340mm	36kg	440+	Match PV & wind turbine system
EP-B-50	5kWh	51.2V,100Ah	CAN+RS485	560×280×360mm	48kg	660+	Mainstream wall-mounted battery pack
EP-B-100	10kWh	51.2V,200Ah	CAN+RS485	680×400×420mm	95kg	1240+	Floor standing, parallel stackable
EP-B-150	15kWh	51.2V,300Ah	CAN+RS485	740×440×460mm	138kg	1810+	Large family / small workshop energy module
EP-B-200	20kWh	51.2V,400Ah	CAN+RS485	800×480×480mm	175kg	2380+	Small commercial energy storage, multi-units parallel

General Notes

FOB price is for reference only, subject to lithium raw material fluctuation and order quantity.
EP-B battery pack must work with compatible hybrid inverter, AC output not available directly.
Full set UN38.3 & CE documents provided for sea shipment.
Support integration with SunPhoton Entry vertical axis wind turbine & solar PV modules for wind-solar-storage hybrid system.
Unified SunPhoton APP for monitoring wind turbine, PV and storage together.
